Service Telephone:86-755-83294757
Trade Name:Analogue-to-Digital Converter - ADC
Brand:ADI
Particular Year:23+
Package:QFN-64
Delivery Date:New and Original
Stock: 2500pcs
The LTC2208IUP is a 130Msps, 16-bit A/D converter designed for digitising high-frequency, wide dynamic range signals with input frequencies up to 700MHz. The input range of this ADC can be optimised using a PGA front end.
The LTC2208IUP is ideal for demanding communication applications, featuring AC performance including a 78dBFS noise floor and 100dB spur-free dynamic range (SFDR). Ultra-low jitter of 70fsRMS enables undersampling at high input frequencies and exceptional noise performance. Maximum DC specifications include ±4LSB INL and ±1LSB DNL (no missing codes).
Digital outputs can be differential LVDS or single-ended CMOS. CMOS outputs offer two format options: a single bus operating at full data rate or a multiplexed bus operating at half data rate. A separate output power supply allows the CMOS output swing to vary between 0.5V and 3.3V.
A sine wave, PECL, LVDS, TTL, or CMOS input can be used to drive the ENC+ and ENC¯ inputs differentially or single-ended. An optional clock duty cycle stabiliser achieves high performance at full speed and under various clock duty cycle conditions.
LTC2208IUP Features
Sampling rate: 130Msps
78dBFS noise floor
100dB SFDR (uncompressed dynamic range)
SFDR > 83dB at 250MHz (1.5VP-P input range)
PGA front end (2.25VP-P or 1.5VP-P input range)
700MHz full-power bandwidth S/H (sampling and holding)
Optional internal high-frequency jitter
Optional data output random function generator
LVDS or CMOS output
Single 3.3V power supply
Power consumption: 1.25W
Clock duty cycle stabiliser
130Msps: LTC2208IUP (16-bit)
64-pin (9mm x 9mm) QFN package
LTC2208IUP Applications
Telecommunications
Receivers
Cellular base stations
Spectrum analysis
Imaging systems
ATE (Automatic Test Equipment)
