The DAC80508MRTER is a member of the low-power eight-channel buffered voltage output digital-to-analog converter (DAC) pin-compatible series, featuring 16-bit resolution. This device includes an internal base voltage standard of 2.5V (5ppm/°C), eliminating the external precise reference required in most applications. The user-selectable gain configuration provides full-scale output voltages of 1.25V (gain = ½), 2.5V (gain = 1), or 5V (gain = 2). The DAC80508MRTER is powered by a single 2.7V to 5.5V power supply, featuring monotonicity and providing a high linearity of ±1 LSB INL.

The performance parameters of DAC80508MRTER are as follows:

Number of digits: 16

Digital-to-analog converter number: 8

Establishment time: 5µs (typical value)

Output type: Voltage-Buffered

Differential output: None

Data interface: SPI

Reference types: External, Internal

Voltage - Power supply, simulation: 2.7V to 5.5V

Voltage - Power supply, digital: 1.7V to 5.5V

INL/DNL (LSB) : ±0.5, ±0.5

Architecture: R-2R

Operating temperature: -40°C to 125°C

Device packaging: 16-WQFN (3x3)

Installation type: Surface mount type

These performance parameters enable the DAC80508MRTER to perform well in various applications, especially in fields such as optical fiber networks, wireless infrastructure, industrial automation, and data acquisition systems.
