The MP2984GR is a high-efficiency, synchronous, 4-switch boost controller that enables regulation of different output voltages over a wide input voltage (VIN) range for USB powered (PD) applications in USB Type-C power supplies. The output voltage (VOUT), VOUT slope, and output constant current limit are configurable through the serial interface.

With valley current control in buck mode and peak current control in boost mode, the MP2984GR provides fast load transient response and smooth boost and ramp mode transients. Its forced continuous conduction mode (FCCM) and adjustable current limit support flexible designs for a variety of applications.

The MP2984GR has comprehensive protection features including adjustable overcurrent protection (OCP), overvoltage protection (OVP), and VIN undervoltage lockout (UVLO) hysteresis.

The MP2984GR is available in a QFN-32 (4mmx4mm) package.

MP2984GR Product Features and Benefits

Wide input operating voltage (VIN) range of 5V to 36V

Wide start-up VIN range of 6V to 36V

Flexible control via serial interface:

0.5V to 28V output voltage (VOUT) range

0.3V to 2.047V reference voltage (VREF) range in 1mV steps

Selectable VOUT slope

Adjustable constant current limit

Adjustable current limit in < 50mA steps via IPWM

Output current monitoring (IMON)

Adjustable soft start time (tSS)

Frequency of switching (fSW) spectrum spreading (FSS) function for reduced EMI

Integrated VOUT discharge function

Selectable fSW at 200kHz, 300kHz, 400kHz or 600kHz

Forced continuous conduction mode (FCCM)

Adjustable VIN undervoltage lockout (UVLO) hysteresis

Ultra-small VIN adjustment

Overcurrent protection (OCP)

Short Circuit Protection (SCP)

Overvoltage Protection (OVP)

OCP, OVP, Over Temperature Protection (OTP) and PNG interrupt indication

Available in QFN-32 (4mmx4mm) package

MP2984GR Applications

USB power delivery (PD)

Industrial PC power supplies
