The AD8410AWBRMZ-10 is a high-voltage, high-bandwidth current-sense amplifier for high-side and low-side current sensing in automotive and industrial applications. It features an initial gain of 20 V/V and a bandwidth of 2.2 MHz with a maximum gain error of ±0.13% and excellent common-mode rejection over the full temperature range.

AD8410AWBRMZ-10 Specification Parameters

Common mode input voltage range: -2V to +70V continuous, -20V to +75V survival

Bandwidth: 2.2 MHz

Gain initial error: 20 V/V, ±0.13% maximum

Voltage offset: ±200 μV maximum

Offset drift: 1.0 μV/°C typical

Operating temperature range:

AD8410WB: -40°C to +125°C

Supply voltage range: 2.9V to 5.5V

Package: 10-pin MSOP

AD8410AWBRMZ-10 Key Features

High common mode input voltage range: -2V to +70V continuous, -20V to +75V survival

Low offset drift: 1.0 µV/°C typical

High bandwidth: 2.2 MHz

High common mode rejection ratio (CMRR): 123 dB (DC to 10 kHz)

Bidirectional operation: Supports bidirectional current measurements

Wide operating temperature range: -40°C to +150°C

Certified for automotive applications: meets standards for automotive applications

AD8410AWBRMZ-10 Product Applications

High-side current detection:

48V/12V DC to DC converters

Motor control

Solenoid valve control

Power management

Low Side Current Detection:

Diagnostic protection
