MAX25249ATPN is high-efficiency, four-output PMICs that integrate three DC-DC converters and a high-PSRR LDO, with OV/UV monitoring on all outputs. OUT1 is a 1A high-voltage synchronous step-down converter operating from power over coax or car battery. OUT2 and OUT3 low-voltage synchronous step-down converters operate from OUT1 and provide a 0.8V to 3.9875V output voltage range. OUT2 can deliver 1.2A for high-megapixel cameras and high-speed serializers. OUT3 can deliver 1.2A to power the secondary rails of the imager, serializer, and MCU. OUT4 is a low-voltage, low-noise, high-PSRR LDO for imager power. All buck converters achieve ±1.5% output voltage accuracy over load, line, and temperature range. Overvoltage and undervoltage faults are monitored with ±1.3% accuracy around the set voltage, and errors are communicated through active-low RESET.

Features Of MAX25249ATPN

Multiple Functions for Small Size

1A Synchronous High-Voltage Buck Converter

Input Voltage Range 5V to 36V

3V to 4V, and 5V Output Voltage in 50mV Steps

Two Synchronous Low-Voltage Buck Converters

OUT2 and OUT3 Provide up to 1.2A

0.8V to 3.9875V in 12.5mV Steps

LDO for Camera Sensor; 50dB at 1kHz

2.2MHz Operation

Active-Low RESET Output – Push-Pull or Open-Drain

High Precision

±1.5% Output Voltage Accuracy

±1.3% OV/UV Monitoring Accuracy

Diagnostics and Features

ASIL B Compliant

Redundant Reference

Robust for the Automotive Environment

Current-Mode, Forced-PWM Operation

Overtemperature and Short-Circuit Protection

3.5mm x 3.5mm 20-Pin TQFN

-40°C to +125°C Grade 1 Automotive Temperature Range

AEC-Q100 Qualified

Applications Of MAX25249ATPN

Front/Rear/Surround View Camera
