Service Telephone:86-755-83294757
Trade Name:RS-422/RS-485 Interface IC
Brand:Maxim
Particular Year:24+
Package:SOIC-8
Delivery Date:New and Original
Stock: 20000pcs
The MAX1483ESA is a low-power transceiver for RS-485 and RS-422 communications. The transceivers feature slew rate limiting drivers to minimise EMI and reduce reflections caused by improperly terminated cables. Data rates are guaranteed up to 250kbps.
MAX1483ESA - Features
Low 20µA operating current
Slew rate limited to reduce EMI and reflections
0.1µA low current shutdown mode
Designed for RS-485 and RS-422 applications
Powered from a single +5V supply
-Common mode input voltage range of -7V to +12V
Guaranteed bus connection for up to 256 transceivers (1/8 unit load)
Current limit and thermal shutdown features provide driver overload protection
MAX1483ESA - Specifications
Type: Transceiver
Protocol: RS422, RS485
Number of Drivers/Receivers: 1/1
Duplex: Half
Receiver Hysteresis: 75 mV
Data Rate: 250kbps
Voltage - Supply: 4.75V ~ 5.25V
Operating Temperature: -40°C ~ 85°C
Mounting Type: Surface Mount
Package/Shell: 8-SOIC (0.154’, 3.90mm Width)
Supplier Device Package: 8-SOIC
MAX1483ESA - Applications
Industrial Control LANs
Large-scale 256-node LANs
Low power RS-485/RS-422 networks
Transceivers for EMI-sensitive applications
