The LTC2863IDD-1 is a low-power RS-485/RS-422 full-duplex transceiver operating from a 3 V to 5.5 V supply, housed in an 8-pin 3 mm × 3 mm DFN-8 package. The device can withstand ±60 V line fault voltages on the differential bus pins in any operating mode (including power-down) and provides ±15 kV HBM ESD protection, making it suitable for high-noise, high-transient industrial field communications.

LTC2863IDD-1 Product Attributes

Product Type: RS-422/RS-485 Interface IC

Series: LTC2863

Mounting Style: SMD/SMT

Package/Case: DFN-8

Function: Transceiver

Number of Drivers: 1 Driver

Number of Receivers: 1 Receiver

Data Rate: 20 Mb/s

Supply Voltage - Maximum: 5.5 V

Minimum Supply Voltage:    3 V

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +85°C

Duplex:    Full Duplex

Input Voltage:    3 V to 5.5 V

Operating Supply Current:    3.3 mA

Operating Supply Voltage:    3.3 V

Output Current:    150 mA

Output Voltage:    5.5 V

LTC2863IDD-1 Applications

Monitoring and Data Acquisition (SCADA)

Industrial Control and Instrumentation Networks

Automotive and Transportation Electronics

Building Automation, Security Systems, and HVAC

Medical Devices

Lighting and Sound System Control
