The MAX3030EEUE is a four-channel RS-422 transmitter introduced by Maxim Integrated, featuring a 16-TSSOP package and compliant with the TIA/EIA-422-B and ITU-T V.11 standards. This chip supports high-speed data transmission at 20 Mbps and includes ±15 kV ESD protection, making it suitable for applications such as industrial communication, motor control, and telecommunications backplanes.

MAX3030EEUE Key Features

20 Mbps high-speed data rate, suitable for high-speed serial communication

±15 kV ESD protection (human body model), enhancing system reliability

Low-power design (static current <100μA), suitable for battery-powered devices

Hot-swap functionality to prevent unintended triggering during power-on or hot-swap operations

3.3V single-supply operation simplifies power design

16-TSSOP package saves PCB space

Technical Specifications

Model: MAX3030EEUE

Package: 16-TSSOP (4.4mm width)

Operating Voltage: 3.0V to 3.6V

Data Rate: 20Mbps

ESD Protection: ±15kV (human body model)

Quiescent Current: <100μA

Propagation Delay: 16ns (maximum)

Operating Temperature: -40°C to +85°C

Interface Standards: RS-422, TIA/EIA-422-B, V.11

Output Type: Differential (3-state output)

Number of Drivers: 4

Number of Receivers: 0

MAX3030EEUE Applications

Industrial PLCs

Motor Control

Telecom Backplanes

V.11/X.21 Interfaces
