Trade Name:RS-485 Interface IC
Brand:TI
Particular Year:24+
Package:SOIC-16
Delivery Date:New and Original
Stock: 12000pcs
ISO1410BDWR devices are galvanically isolated differential line transceivers for TIA/EIA RS-485 and RS-422 applications. These noise immunity transceivers are designed for use in harsh industrial environments.
Features of the ISO1410BDWR
Compliant with TIA/EIA-485-A standard
PROFIBUS application compliant with 5V bus-side power supply
Bus I/O protection
±30kV HBM
±16kV IEC 61000-4-2 Contact Discharge
±4kV IEC 61000-4-4 Electrical fast transients
Low EMI 500kbps, 12Mbps and 50Mbps data rates
1.71V to 5.5V logic-side supply (VCC1), 3V to 5.5V bus-side supply (VCC2)
Receiver failsafe for bus opens, shorts and idles
1/8 unit load: up to 256 bus nodes
High common-mode transient immunity of 100kV/µs (typical)
Operating temperature range of -40°C to 125°C
Trouble-free power-up and power-down for hot-swap functionality
Wide-body SOIC-16 package
Pin compatible with most isolated RS-485 transceivers
Applications for ISO1410BDWR
- Grid infrastructure
- Photovoltaic inverters
- Factory automation and control
- Motor drives
- HVAC systems and building automation
