The ADS1013QNKSRQ1 device is an automotive 12-bit 3.3kSPS single-channel Delta-σ ADC with oscillator, voltage reference, and I2C. The device has a wide operating supply voltage range, making it ideal for power - and space-constrained sensor measurement applications.

The ADS1013-Q1 performs conversions at data rates up to 3,300 samples per second (SPS). PGA offers an input range from ±256mV to ±6.144V for accurate size signal measurement.

Features:

• Complies with AEC-Q100 standard for automotive applications:

- Temperature Class 1: -40 °C to +125°C, TA

• Functional safety

- Documentation to help design functional safety systems

• Noise-free resolution: 12 bits

• Wide supply voltage range: 2.0V to 5.5V

• Low current consumption: 150μA (continuous conversion mode)

Programmable data rate: 128SPS to 3.3kSPS

• Single cycle stability

• Internal low drift voltage reference

• Internal oscillator

• I2C interface: Four pin optional addresses

• Device series:

ADS1013-Q1:1 single-ended (SE) or differential input (DE)

ADS1014-Q1:1 single-ended or differential input with comparator and PGA

ADS1015-Q1:4 single-ended inputs or 2 differential inputs, with comparator and PGA

Applications:

• Camera module with no processing function

• Automotive center information display

• Automotive instrument group display

• Universal voltage and current monitoring
