The MAX20410EAFOF/VY is a highly integrated synchronous buck converter for automotive applications with internal high and low side switches. The IC is designed to deliver up to 10A current with an input voltage range of 3.0V to 36V. The PGOOD signal monitors voltage quality.

Features:

High power DC/DC converter with small solution size

Operating input voltage range: 3.0V to 36V

Integrate high - and low-side FETs

Maximum output current: 8A/10A

Fixed frequency options: 400kHz and 2.1MHz

Fixed soft startup time: 2.5ms

Minimum on-time: 34ns

Programmable 0.8V to 10V output, 400kHz, 0.8V to 6V output, 2.1MHz or fixed options

Output voltage accuracy: ±1.8%

Symmetrical and balanced SUP and PGND pin distribution layout for excellent EMI performance

Thermal enhanced 3.5mm x 3.75mm, 17-pin FC2QFN package

High efficiency in all load ranges

The static current in skip mode is 10μA

Up to 94.3% efficiency (12VIN/5VOUT/2.1MHz)

Up to 95.6% efficiency (12VIN/5VOUT/400kHz)

Dual-phase operation with load capacity up to 20 A

Frequency synchronization input/output

180º out-of-phase between master and slave devices

Dynamic current sharing

Reliable operation in automotive environment

Force PWM and jump mode operation

Low pressure differential operation: 99% duty cycle

Support 42V load drop

Spread spectrum option

Power good indicator

Overheating and short circuit protection

Automotive grade temperature range: -40°C to +125°C

Meets AEC-Q100 standard

Scalable power solutions

The placeholder size is compatible with MAX20404, MAX20405 and MAX20406

3.5mmx3.75mm FC2QFN-17 package
