Trade Name:ADN4620BRSZ
Data Manual:ADN4620BRSZ.pdf
Brand:ADI
Particular Year:23+
Package:20-SSOP
Delivery Date:New and Original
Stock: 2000pcs
ADN4620BRSZ Device Overview:
The ADN4620/ADN46211 are dual, signal-isolated, low-voltage differential signal (LVDS) buffers that operate at speeds up to 2.5 Gbps with extremely low jitter. These devices integrate Analog Devices, Inc.'s iCoupler® technology, which is enhanced for high-speed operation, to provide drop-in galvanic isolation for the LVDS signal chain. AC coupling and/or level translation to the LVDS receiver and LVDS driver allows isolation of other high speed signals such as current mode logic (CML).
The ADN4620/ADN4621 include a refresh mechanism to monitor the input and output states and ensure that they remain unchanged in the absence of data transitions (e.g. at power-up). To achieve lower power consumption and low jitter for high speed operation, the isolator circuitry relies on a 1.8 V supply, while a 3.3 V supply is used for the LVDS receiver to support the full common mode range with an input voltage range (input common mode plus differential input voltage) of 0 V to 2.4 V, see Table 2.
The ADN4620 and ADN4621 have a wide industrial temperature range and are available in a compact SSOP package with a creepage distance of 5.3 mm (for enhanced insulation at AC supply voltages).
Features
3.75kVrms LVDS isolator
TIA/EIA-644-A LVDS signal level compliant
Dual channel configuration (ADN4620: 2 + 0, ADN4621: 1 + 1)
Capable of switching at any data rate up to 2.5Gbps with low jitter
Total bandwidth on both channels: 5Gbps
Propagation delay: 2.15ns (typical)
Typical jitter: 0.82ps rms random, 40ps total peak-to-peak
Low power 1.8V supply, 3.3V supply for I/O
±7kV IEC 61000-4-2 ESD protection (entire isolation gate)
High common mode transient rejection: 70kV/μs (typical)
Safety and regulatory approval (20-pin SSOP package)
UL (pending): 3750V rms for 1 minute to UL 1577
CSA Component Approval Notice 5A (in progress)
VDE Certificate of Conformity, Enhanced Insulation (application in progress)
DIN V VDE V 0884-11 (VDE V 0884-11): 2017-01
VIORM = 1500VPEAK (maximum working insulation voltage)
Refresh enabled or disabled (low speed output correctness check)
Operating temperature range: -40°C to +125°C
Compact SSOP package with a creepage distance of 5.3mm
Applications
Analogue front-end isolation
Data plane isolation
Isolated high-speed clock and data links
Multi-gigabit serialisation/deserialisation (SERDES)
PCB-to-PCB optical alternatives (e.g. short-haul fibre)
Model
Brand
Package
Quantity
Describe
Skyworks
SOIC-16
15000
General Purpose Digital Isolator 5000 Vrms 6 Channels 150 Mbps 35 kV/µs CMTI 16-SOIC (0.295", 7.50 mm wide)
TI
SOIC-16
12000
Low power consumption, four channels, 3/1, 25Mbps, default output low level digital isolator
ADI
SOIC-20
2000
5 kV dedicated isolator for SPI interface (2/1 auxiliary channel directionality)
ADI
SOIC-16
4000
Quad-channel digital isolator with enhanced system-level ESD reliability
