Trade Name:Switching Regulators
Brand:TI
Particular Year:24+
Package:WSON12
Delivery Date:New and Original
Stock: 10000pcs
The TPS62742DSSR is the industry's first buck converter to feature 360nA typical quiescent current and operate with a tiny 2.2µH inductor and 10µF output capacitance. This new DCS-Control™-based device extends the light-load efficiency range to below 10µA load current.
TPS62742DSSR Product Attributes:
Manufacturer: Texas Instruments
Product Category: Switching Regulator
Output Voltage: 1.8 V to 3.3 V
Output Current: 400 mA
Number of Outputs: 1 Output
Topology: Buck
Package / Case: WSON-12
Mounting style: SMD/SMT
Switching frequency: 2 MHz
Quiescent current: 360 nA
Minimum Operating Temperature: - 40 C
Maximum operating temperature: + 85 C
Series: TPS62742
Height: 0.8 mm
Length: 3 mm
Operating Supply Current: 300 nA
Product Type: Switching Voltage Regulators
Factory Package Quantity: 3000
Sub Category: PMIC - Power Management ICs
Width: 2.1 mm
Unit Weight: 13.200 mg
The TPS62742DSSR is available in a small 12-pin 2mm x 3mm2 WSON package and supports an overall solution size of 31mm2.
Applications
Bluetooth® Low Energy, RF for consumer electronics (RF4CE), short-range low-power communication technology (Zigbee)
Industrial metering
Energy Harvesting
