The SN65C3232PWR consists of two line drivers, two line receivers, and a dual-channel charge pump circuit, featuring pin-to-pin (serial port connection pins, including GND) ±15kV ESD protection. These devices provide an electrical interface between asynchronous communication controllers and serial port connectors. The charge pump and four small external capacitors support single-supply operation from 3V to 5.5V. The device operates at a typical data signal transfer rate of up to 1Mbit/s, with driver output slew rates ranging from 24V/µs to 150V/µs.

SN65C3232PWR Features

• Powered by a 3V to 5.5V VCC power supply

• Data rates up to 1Mbit/s

• Low power consumption: 300μA (typical)

• External capacitors: 4 × 0.1μF

• Accepts 5V logic inputs and 3.3V power supply

• RS-232 bus pins ESD protection greater than ±15kV human body model (HBM)

SN65C3232PWR Product Attributes

Type: Transceiver

Protocol: RS232

Driver/Receiver Count: 2/2

Duplex: Full

Receiver hysteresis: 300 mV

Data rate: 1 Mbps

Voltage - Power supply: 3V to 5.5V

Operating temperature: -40°C to 85°C

Mounting type: Surface mount

Package/housing: 16-TSSOP (0.173", 4.40mm wide)

SN65C3232PWR Applications

• Industrial PCs

• Wired networks

• Data centres and enterprise computing

• Battery-powered systems

• Laptops

• Laptops

• Handheld computers

• Handheld devices
