Service Telephone:86-755-83294757
Trade Name:RF Mixers
Brand:Mini-Circuits
Particular Year:24+
Package:QFN-24
Delivery Date:New and Original
Stock: 3000pcs
SMIQ-1844H: 18GHz - 40GHz, Wideband In-phase/Quadrature (I/Q) Mixer
SMIQ-1844H Product Description:
The SMIQ-1844H+ is a passive wideband in-phase/quadrature (I/Q) mixer fabricated using GaAs HBT technology. The SMIQ1844H+ is usable as a single sideband upconverter for transmit applications or an image rejection mixer for receiver applications. The SMIQ-1844H+ is ideal for wideband frequency translation applications that require inherent rejection of image signals and spurious mixing products. The mixer covers a broad band with RF and LO frequency ranges of 18 to 40 GHz and an IF frequency range of DC to 7 GHz. As a passive mixer, the SMIQ-1844H+ offers lower noise figure than active mixers enabling superior dynamic range for high performance applications. The mixer is housed in a compact 4x4 mm 24-Lead QFN-style package, and no DC bias is needed for operation.
SMIQ-1844H Product Features:
Wideband RF & LO, 18GHz to 40GHz
Wideband IF, DC to 7 GHz
Excellent Image Rejection, Typ. 30 dB
High LO-RF Isolation, Typ. 38 dB
High Input IP3, Typ. +31 dBm
Usable as Image Reject Mixer & SSB Converter
4x4 mm, 24-Lead QFN-Style Package
SMIQ-1844H Applications:
Test and Measurement Equipment
5G mmWave and Back Haul Radio
Satellite Communications
Radar, EW, and ECM Defense Systems
SMIQ-1844H Functional Diagram:
