Description: The RC32504A000GNK is a small, low-power timing device designed to be placed next to a PHY, switch, ASIC or FPGA that requires several reference clocks with jitter performance of less than 100fs.

RC32504A000GNK

Type: Frequency converter

PLL: Yes

Input: HCSL, LVCMOS, LVDS, Crystal

Output: CML, HCSL, LVCMOS, LVDS, LVPECL

Circuit number: 1

Ratio - Input: Output: 2:5

Difference - Input: Output: Yes/yes

Frequency - Max: 180MHz, 1GHz

Frequency divider/frequency multiplier: Yes/none

Voltage - power supply: 1.71V ~ 1.89V, 3.465V

Operating temperature: -40°C ~ 85°C (TA)

Mounting type: Surface mount type

Package/housing: 24-WFQFN bare pad

Supplier Package: 24-VFQFPN (4x4)

The RC32504A can be used as a frequency synthesizer to generate a reference clock locally, as a jitter attenuator to perform local clear and/or frequency conversion on a centrally supplied reference, as a synchronous Ethernet device clock to perform passband filtering and clear on a network supplied reference, or as a DCO for frequency margin fine-tuning or OTN clock applications.

Applications:

Synchronize Ethernet /OTN devices

Reference clock generator for 100Gbps/400Gbps PHY or switch

Adjustable OTN clock reference for OTU3/OTU4 plotters

Reference clock for programmable fiber module
