The LM5168PDDAR synchronous buck converter is used to regulate over a wide input voltage range, minimizing the need for external surge suppression elements. The minimum controllable on-time of 50ns facilitates a large step-down conversion ratio, enabling direct step-down conversion from a 48V nominal input to a low voltage rail, reducing system complexity and solution costs. The LM516x is capable of operating at nearly 100% duty cycle when input voltage drops sharply to 6V, as required, making it ideal for industrial and high-count battery pack applications with a wide input voltage range.

Specifications:

Product model: LM5168PDDAR

Function: Depressurize

Output configuration: positive

Topology: depressurize

Output type: Adjustable

Output number: 1

Voltage - input (min) : 6V

Voltage - Input (Max) : 120V

Voltage - output (min/fixed) : 1.2V

Voltage - output (Max) : 120V

Current - Output: 300mA

Frequency-switch: 100kHz ~ 1MHz

Synchronous rectifier: Yes

Operating temperature: -40°C ~ 150°C (TJ)

Mounting type: Surface mount type

Package/Housing: 8-PowerSOIC (0.154", 3.90mm wide)

Supplier component package: 8-SO-PowerPad

Basic product number: LM5168
