The SI8610ED-B-ISR is a CMOS device that offers the advantages of CMOS devices in terms of data rate, propagation delay power, size, reliability and external BOM. The operating parameters of these products remain stable throughout the life of the device, allowing for ease of design and a high degree of uniformity in performance. Highly uniform. All device versions feature Schmitt-triggered inputs for high noise immunity and require only VDD bypass capacitors. Supports data rates up to 150 Mbps with less than 10 ns propagation delay in all devices.

Product Characteristics

Technology: Capacitively coupled

Type: General Purpose

Isolated Power: None

Number of Channels: 1

Input - Side 1/Side 2: 1/0

Channel type: Unidirectional

Isolation voltage: 5000 Vrms

Common mode transient immunity (min): 35 kV/µs 35 kV/µs

Data rate: 150 Mbps 150 Mbps

Propagation delay tpLH / tpHL (max): 13ns, 13ns 13ns, 13ns

Pulse width distortion (max): 4.5ns 4.5ns

Rise / decay time (typical): 2.5ns, 2.5ns 2.5ns, 2.5ns

Voltage - Supply: 2.5V ~ 5.5V

Operating Temperature: -40°C ~ 125°C

Mounting Type: Surface Mount

Package/Case: 16-SOIC (0.295" wide, 7.50 mm)

Delivery Included: 16-SOIC

Applications

● Industrial automation systems

● Medical electronics

● Isolated switch mode power supplies

● Isolated ADCs, DACs

● Motor control

● Power inverters

● Communication systems
