The ADM3251EARWZ is a high-speed, 2.5 kV fully isolated single-channel RS-232/V.28 transceiver device powered by a single 5 V supply. Thanks to the high ESD protection of the RIN and TOUT pins, the device is ideally suited for operation in electrically harsh environments or where RS-232 cables are frequently plugged and unplugged.

Product specifications

Series: IsoPower®, iCoupler®

Packaging: Tubes

Technology: Magnetically coupled

Type: RS232

Isolated power supply: Yes

Number of channels: 2

Input - Side 1/Side 2: 1/1

Channel Type: Unidirectional

Voltage - isolated: 2500Vrms

Common Mode Transient Immunity (min): 25kV/µs

Data Rate: 460Kbps

Propagation delay tpLH / tpHL (max): 135ns, 190ns

Pulse width distortion (max): -

Rise/fall time (typical): 2.3ns, 2.3ns

Voltage - Supply: 4.5V ~ 5.5V

Operating Temperature : -40°C ~ 85°C

Mounting Type: Surface Mount Type

Package/Case: 20-SOIC (0.295", 7.50 mm wide)

Supplier Device Package: 20-SOIC

Base Part Number: ADSM3251

Applications

High noise data communications

Industrial communications

General purpose RS232 data link

Industrial/telecom diagnostic ports

Medical equipment
