The MAX38640BENT18 is a nanoPower family of ultra-low 330nA quiescent current step-down (buck) DCDC converters that operate from 1.8V to 5.5V, support load currents up to 175mA, 350mA, and 700mA, and have 96% peak efficiency. With a shutdown current of only 5nA, these devices offer ultra-low quiescent current, small overall solution size, and high efficiency over the full load range. the MAX38640-MAX38643 are ideal for battery applications requiring long battery life.

Benefits and Features

● Extended battery life

- 330nA ultra-low quiescent supply current

- 5nA shutdown current

- 96% peak efficiency, over 88% at 10µA

● Easy to use - solves popular operational problems

- 1.8V to 5.5V input range

- 0.7V to 3.3V Single resistor adjustable VOUT (A option)

- 0.5V to 5.0V pre-programmed VOUT (B option)

- ±1.75% Output Voltage Accuracy

- Up to 175mA/350mA/700mA load current

● Protects the system in a variety of use cases

- Reverse current blocking on shutdown

- Optional active discharge function

● Reduced size for increased reliability

- Temperature range: -40°C to +85°C

- 2mm x 2mm, 6-pin µDFN package

- 1.42mm x 0.89mm, 0.4mm pitch 6-pin (2 x 3) WLP

Applications

Space-constrained portable consumer products

Wearables, ultra-low power IoT, NB IoT and Bluetooth® LE

Single cell lithium ion (Li+) and coin cell products

Wired or wireless industrial products
