Service Telephone:86-755-83294757
Trade Name:Switching Regulator
Brand:TI
Particular Year:22+
Package:HSOIC-8
Delivery Date:New and Original
Stock: 2250pcs
The LM22674MRE-5.0 is a high-performance buck converter introduced by Texas Instruments, part of the SIMPLE SWITCHER® series. This chip is specifically designed for applications requiring efficient and highly reliable power conversion, featuring a wide input voltage range, high efficiency, and a compact package.
LM22674MRE-5.0 Product Features
Wide input voltage range: 4.5V to 42V
Fixed output voltage: 5V
Maximum output current: 500mA
High efficiency: Maintains high efficiency across a wide input-output voltage range, up to 90%
Voltage-mode control: Provides a short minimum on-time, suitable for wide input-output voltage ratios
Internal loop compensation: Simplifies design by eliminating the need for external compensation components
Integrated protection features: Includes thermal shutdown and current limiting to prevent overloads
Precision enable pin: Simplifies regulator control and system power sequencing
Integrated soft-start: Typical value of 500µs, reducing the need for external components
Compact packaging: Uses an 8-pin PowerSOIC package, saving space
LM22674MRE-5.0 Technical Specifications
Input voltage range: 4.5V to 42V
Output voltage: 5V
Maximum output current: 500mA
Switching frequency: 500kHz
Operating temperature range: -40°C to 125°C
Package type: 8-pin PowerSOIC
Quiescent current: Typical value 3.4mA
Standby current: Typical value 25µA
Application Areas
The LM22674MRE-5.0 is widely used in the following areas:
Industrial Control: Provides efficient power conversion for various industrial equipment.
Telecommunications and Data Communication Systems: Suitable for communication base stations and data centres.
Embedded Systems: Provides stable power supply for embedded devices.
Standard Input Power Rail Conversion: Suitable for standard power rails such as 24V, 12V, and 5V.
