Commodity Model:TDP158RSBR

Trade Name:TDP158RSBR

Data Manual:TDP158.pdf

Brand:TI

Particular Year:21+

Package:WQFN-40

Delivery Date:New and Original

Stock: 30000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
TI
Model
TDP158RSBR
Package
WQFN-40
Describe
HDMI interface 40-WQFN (5x5)

Product Description

The TDP158 device is an AC-coupled HDMI to Transition Minimized Differential Signaling (TMDS) redriver supporting Digital Visual Interface (DVI) 1.0 and High Definition Multimedia Interface (HDMI) 1.4b and 2.0b output signals. The TDP158 supports four TMDS channels and a digital display control (DDC) interface. Upstream signaling rates up to 6 Gbps are supported to allow resolutions up to 4k2k60p with 24 bits per pixel, up to WUXGA 16-bit color depth or 1080p with higher refresh rates. The TDP158 can be configured to support HDMI2.0 standard.


The TDP158 supports dual supply rails of 1.1 V on V DD and 3.3 V on V CC for power reduction. Some methods of power management are implemented to reduce overall power consumption. The TDP158 supports the use of I 2 C or pin strips to compensate for different lengths of input cable or board traces.


Features

• AC-coupled receiver supports AC-coupled HDMI or DP++ signaling data rates up to 6 Gbps

• Transmitter compatible with HDMI TMDS electrical parameters up to 6 Gbps

• Supports 4k2k60p and up to WUXGA 16-bit color depth or 1080p with higher refresh rates.

• Up to 15 programmable fixed receiver equalizers D b

• Global or independent high-speed lane control

• I 2 C or pin with programmable

• Transmitter swing, pre-emphasis, slew rate and termination programmable via pin-strapping or I2C

• Configurable as DisplayPort redriver via I2C

• 40-pin, 5 mm x 5 mm, 0.4 mm pitch QFN package

• Extended commercial temperature support 0°C – 85°C (TDP158)

• Industrial temperature support –40°C to 85°C (TDP158I)

• Pin compatible retimer with SN65/75DP159RSB


Application

• Laptop market

• Audio/video equipment

• Blu-ray™ DVD

• Desktop/All-in-One

•pill

• Gaming system
