Trade Name:Smart Card Interface
Brand:Maxim
Particular Year:22+
Package:TSSOP-28
Delivery Date:New and Original
Stock: 4000pcs
The DS8023-RJX smart card interface IC is a low-cost, low-power analogue front-end for all ISO 7816, EMV*, and GSM11-11 applications.The DS8023-RJX supports 5V, 3V, and 1.8V smart cards and offers a low-power standby mode.The DS8023-RJX is available in a 28-pin TSSOP package and can be used with little or no modification when replacing the TDA8024. The DS8023-RJX is available in a 28-pin TSSOP package and requires little or no modification to replace the TDA8024.
The DS8023-RJX is used to interface the system microprocessor to the smart card interface, providing all the power supplies, protection circuits, and level shifters required for IC card applications.
Applications - DS8023-RJX
Access Control
ATMs
Banking equipment
Debit/credit card payment terminals
Pay TV
PIN Pad
POS Terminal
Set-top Box Authorised Access
Telecommunications
Specification--DS8023-RJX
Product Category: Smart Card Interface IC
Supply Voltage-Minimum: 2.7 V
Supply Voltage-Max: 6 V
Operating supply current: 500 uA
Minimum operating temperature: - 40 C
Maximum operating temperature: + 85 C
Pd-Power dissipation: 700 mW
Mounting style: SMD/SMT
Package / Case: TSSOP-28
Features - DS8023-RJX
Analogue interface and level shifter for IC card communication
Card interface with ±8kV (min) ESD (IEC) protection
Ultra-low current loss in standby mode, less than 10nA (typical)
Internally generated IC card supply voltage:
5.0V ±5%, 80mA (max)
3.0V ±8%, 65mA (max)
1.8V ±10%, 30mA (max.)
Automatic control of card activation and deactivation by internal dedicated sequencing circuitry
Direct level switching of host I/O ports for smart card communication
Flexible generation of card clock, supporting 1, 2, 4, 8 divisions of external crystals
High-current protection, short-circuit protection and overheating protection.
Model
Brand
Package
Quantity
Describe
