The TCAN1043GDRQ1 is an automotive-grade CAN FD (Flexible Data Rate) transceiver compliant with the AEC-Q100 standard, packaged in a 14-SOIC package, supporting a maximum data rate of 5 Mbps (the model suffix ‘G’ indicates support for 5 Mbps CAN FD). This device complies with the ISO 11898-2 (2016) high-speed CAN physical layer specification, providing a stable communication interface in 12V/24V automotive systems. It is suitable for applications such as ADAS (Advanced Driver Assistance Systems), Body Control Modules (BCM), infotainment systems, and vehicle gateways.

TCAN1043GDRQ1 Product Attributes

Product Type:    CAN Interface Integrated Circuit

Series:    TCAN1043G

Mounting Style:    SMD/SMT

Package/Case:    SOIC-14

Data Rate:    5 Mb/s

Number of Drivers:    1 Driver

Number of Receivers:    1 Receiver

Supply Voltage - Minimum:    4.5 V

Supply Voltage - Maximum:    5.5 V

Minimum Operating Temperature:    -55°C

Maximum Operating Temperature:    +125°C

Operating Supply Current:    70 mA

ESD Protection:    15 kV

Qualification:    AEC-Q100

Interface Type:    CAN

Isolation Type:    Non-Isolated

Operating Power Supply Voltage:    4.5 V to 5.5 V

Output Type:    Differential

Pd-Power Dissipation:    126 mW

TCAN1043GDRQ1 Applications

• 12V or 24V system applications

• Automotive and transportation

– Advanced Driver Assistance Systems (ADAS)

– Infotainment systems

– Instrument clusters

– Body electronics and lighting
