The TPS92611QDGNRQ1 device is a simple, single-channel, high-side LED driver powered by an automotive battery. It is a simple and clever solution to provide constant current to a single LED string with LED diagnostics.

TPS92611QDGNRQ1 Features

Compliant with automotive applications

- The following features are compliant with the AEC-Q100 standard:

- Temperature Class 1: -40°C to 125°C ambient operating temperature range

- Device HBM ESD Classification H2

- Device CDM ESD Classification C3B

- Providing Functional Safety

- Documentation to help create functionally safe system designs

- Single-Channel Constant-Current LED Driver with PWM Dimming

- Wide input voltage range: 4.5V - 40V

- Constant output current, adjustable via sense resistor

- Highly accurate current regulation with ±4.6% tolerance

- Maximum current: 300mA

- Thermal sharing with external resistors

- Low dropout voltage (including current sense dropout)

- Low dropout voltage (including current sense dropout) Maximum dropout: 150mV at 10mA

- Low dropout voltage (including current sense dropout) Maximum dropout: 150mV at 10mA Maximum dropout: 400mV at 70mA

- Maximum drop: 700mV at 150mA Maximum drop: 400mV at 70mA Maximum drop: 700mV at 150mA

- Maximum dropout voltage: 1.3V at 300mA

- Diagnostics and Protection

- Open and short circuit LED detection with auto recovery function

- Diagnostic support with adjustable thresholds for low dropout operation

- Fault bus for up to 15 devices, configurable as ‘cascade fail’ or ‘fail-only channel shutdown

- Low quiescent and fault mode currents (less than 250µA per device)

- Operating junction temperature range: -40°C to 150°C

TPS92611QDGNRQ1 Applications

- Automotive convenience lighting: cabin headlamps, door handles, reading lights and other lamps

- Automotive taillights, centre high mounted brake lights, side marker lights, blind spot monitoring indicators, charging port indicators

- General Purpose LED Driver Applications
