LTC3824IMSE: High Voltage Buck Controller with 40μA Quiescent Current, MSOP-10

Overview:

The LTC3824IMSE is a buck DC/DC controller designed to drive an external P-channel MOSFET. With a wide input range of 4V to 60V and a high-voltage gate driver, the LTC3824IMSE is well-suited for numerous industrial and automotive high-power applications. Constant-frequency current-mode operation delivers outstanding performance.

The LTC3824IMSE can be configured for Burst Mode operation. Burst Mode operation enhances low-current efficiency (quiescent current as low as 40μA) and extends battery runtime. Switching frequency can be set up to 600kHz and is easily synchronisable.

LTC3824IMSE Specifications:

Output Type: Transistor Driver

Function: Buck

Output Configuration: Positive

Topology: Buck

Number of Outputs: 1

Output Stages: 1

Voltage - Supply (Vcc/Vdd): 4V to 60V

Frequency - Switching: 200kHz to 600kHz

Duty Cycle (Max): 100%

Synchronous Rectifier: None

Clock Synchronisation: Yes

Control Features: Current limiting, frequency control, ramp, soft start

Operating Temperature: -40°C to 125°C (TJ)

Mounting Type: Surface Mount

Package/Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm width) Bare Pad

Supplier Device Package: 10-MSOP-EP

LTC3824IMSE Product Features:

Wide Input Range: 4V to 60V

Current-Mode Constant-Frequency PWM

Ultra-Low Dropout Operation: 100% Duty Cycle

Programmable Switching Frequency: 200kHz to 600kHz

Optional High-Efficiency Burst Mode® Operation: 40μA Quiescent Current

Simplified Synchronisation

8V, 2A Gate Drive for Industrial High-Voltage P-Channel MOSFETs (VCC > 10V)

Programmable Soft Start

Programmable Current Limit

LTC3824IMSE Applications:

Industrial and Automotive Power Supplies

Telecom Power Supplies

Distributed Power Systems
