The AD8566ARMZ is a low-cost, single-supply, rail-to-rail input and output operational amplifier optimised for LCD monitor applications. It is manufactured using an advanced high-voltage CMOS process. The AD8566ARMZ incorporates two amplifiers.

These LCD operational amplifiers feature high slew rates, 35 mA continuous output drive current, 250 mA peak output drive current, and high capacitive load drive capability. They offer a wide supply voltage range with a bias voltage below 10 mV. The AD8566ARMZ is ideal for LCD grey-scale reference voltage buffering and VCOM applications.

The AD8566ARMZ is rated for operation over a temperature range of −40°C to +85°C. The dual amplifier is available in an 8-pin MSOP package.

AD8566ARMZ Product Attributes

Product Type: Operational Amplifier - Op Amp

Number of Channels: 2 Channel

GBP - Gain-Bandwidth Product: 5 MHz

SR - Slew Rate: 6 V/μs

Vos - Input Offset Voltage: 2 mV

Ib - Input Bias Current: 80 nA

Supply Voltage - Maximum:    16 V

Supply Voltage - Minimum:    4.5 V

Supply Current:    1.7 mA

Output Current per Channel:    35 mA

CMRR - Common-Mode Rejection Ratio:    95 dB

en - Input Voltage Noise Density:    26 nV/√Hz

Package / Case:    MSOP-8

Mounting Style:    SMD/SMT

Shutdown:    No Shutdown

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +85°C

Series:    AD8566

AD8566ARMZ Applications

LCD Reference Voltage Drivers

Portable Electronics

Communication Equipment

In-Vehicle Infotainment Systems
