The 8V79S680NLGI is a fully integrated clock and SYSREF signal ffan buffer, suitable for JESD204B applications. The 8V79S680NLGI is a high-performance clock and converter synchronization solution specifically designed for circuit boards of wireless base station radio equipment, conforming to JESD204B Subclass 0, 1 and 2 standards. The main function of this device is to distribute and fan out the high-frequency clock and low-frequency system reference signals generated by the JESB204B clock generator (such as 8V19N480), thereby expanding its fan-out function and providing additional phase delay.

The 8V79S680NLGI has been optimized to provide A clock with extremely low phase noise and precise, phase-adjustable SYSREF synchronization signals, meeting the implementation requirements of GSM, WCDMA, LTE, and LTE-A radio boards. Low offset output, low inter-device offset characteristics, and fast output rise/fall times help the system design achieve deterministic clock and SYSREF phase relationships across devices.

The 8V79S680NLGI mainly has the following technical parameters:

Type: Fan-out buffer (allocation), divider

Number of circuits: 4

Ratio - Input: Output: 2:16

Differential - Input: Output: Yes/Yes

Input: Clock

Output: LVDS, LVPECL

Frequency - Maximum: 3 GHz

Voltage - Power supply: 3.135V to 3.465V

Operating temperature: -40°C to 85°C

Installation type: Surface mount type

Package/Housing: 64-VFQFN
