The SI53152-A01AGMR is a PCI Express (PCIe) clock buffer in a 24-QFN (4x4) package, designed for high-speed data transmission systems. This device supports PCIe Gen1/Gen2/Gen3/Gen4 standards, providing low jitter and high-precision clock distribution, suitable for applications such as servers, storage devices, and communication infrastructure.

SI53152-A01AGMR Features

Compatible with PCI-Express Gen 1, Gen 2, Gen 3, and Gen 4 universal clocks

Supports 100 MHz frequency Serial ATA (SATA)

Operating frequency range: 100–210 MHz

Low-power, push-pull, differential output buffers

Internal termination design for maximum integration

Each clock features a dedicated output enable pin

Two PCI-Express buffered clock outputs

Supports LVDS output

I2C support with readback functionality

Extended temperature range: –40 to 85 °C

3.3 V power supply

24-pin QFN package

SI53152-A01AGMR Specifications

Manufacturer: Skyworks Solutions Inc.

Package: 24-QFN (4x4)

Input type: Clock/crystal

Output type: HCSL (High-Speed Current-Driven Logic)

Maximum frequency: 100 MHz

Supply voltage: 3.135 V to 3.465 V

Operating temperature: –40 °C to +85 °C

PLL support: None (pure buffer)

Differential input/output: Single-ended input, differential output

SI53152-A01AGMR Applications

Network-attached storage

Multifunction printer

Wireless access point

Router
