The MAX9263GCB is a Gigabit Multimedia Serial Link (GMSL) serialiser from Maxim Integrated that supports HDCP encryption and is designed for high-bandwidth digital video transmission. The chip is available in a 64-TQFP-EP package (10×10mm) with an operating temperature range of -40°C to +105°C. It meets AEC-Q100 automotive-grade standards for high-reliability scenarios such as in-vehicle entertainment systems and industrial cameras.

Features of MAX9263GCB

HDCP encryption enable/disable can be set via the control channel

Control signal processing for all HDCP protocols - no separate control bus required

HDCP key pre-set in non-volatile secure memory

2.5Gbps net payload data rate (rated at 3.125Gbps)

AC-coupled serial link with 8b/10b line coding

8.33MHz to 104MHz (24-bit mode) or 6.25MHz to 78MHz (32-bit mode) pixel clock

4-bit to 32-bit word length, 8kHz to 192kHz I²S audio channels support HD audio

Built-in half/full duplex bidirectional control channel

Basic mode: 9.6kbps to 1Mbps

Bypass mode: 9.6kbps to 1Mbps

Interrupt support with touch screen

Remote I²C host control peripherals

Programmable pre-emphasis/de-emphasis and channel equaliser to drive 3.125Gbps data 15m down the cable

Serial or Parallel Outputs Provide Programmable Spread Spectrum for Reduced EMI

Deserialiser provides serial data clock recovery without external reference clock

Automatic data rate detection allows ‘real-time’ data rate changes

Serialiser pixel clock input can bypass PLL for jitter attenuation

Built-in PRBS generator/detector for serial link BER testing

Serial link short-to-ground, short-to-battery, and open-circuit faults can be detected

ISO 10605 and IEC 61000-4-2 ESD protection

MAX9263GCB Specifications

Package: 64-TQFP-EP (exposed pads)

Input type: CMOS/LVCMOS (24/32-bit)

Output type: CML (1 differential output)

Data Rate: 2.5Gbps (3.125Gbps max)

Operating Temperature: -40°C ~ +105°C (Automotive Grade)

Supply Voltage: 1.7V ~ 3.6V (Core), 1.8V ~ 3.3V (I/O)

Applications Of MAX9263GCB

High-resolution automotive navigation

Megapixel camera systems

Rear seat information terminals
