The DS90UB929TRGCRQ1 is an HDMI to FPD-Link III bridge device that works in conjunction with the FPD-Link III DS90UB926Q-Q1/DS90UB928Q-Q1 deserialisers to provide a single-channel, high-speed, serial stream over a cost-effective 50Ω single-ended coaxial cable or a 100Ω differential shielded twisted-pair (STP) cable. serial stream over cost-effective 50Ω single-ended coaxial or 100Ω differential shielded twisted pair (STP) cable. The device serialises HDMI v1.4b inputs and supports up to WXGA and 720p video resolutions (24-bit colour depth) The DS90UB929TRGCRQ1 is also compatible with the DS90UB940-Q1/DS90UB948-Q1 deserialisers.

The FPD-Link III interface supports video and audio data transmission and full-duplex control (including I2C communication) over the same differential link. The integration of video data and control over a single differential pair reduces interconnect size and weight and simplifies system design. Electromagnetic interference (EMI) is further reduced through the use of low-voltage differential signalling, data permutation and random generation.

The DS90UB929TRGCRQ1 supports multi-channel audio reception via HDMI or an external I2S interface. The device also provides an optional auxiliary audio interface.

DS90UB929TRGCRQ1 Features

- Compliant with AEC-Q100 for automotive applications

- Device temperature class 2: -40°C to +105°C, TA

- TMDS clock up to 96MHz, supports WXGA and 720p60 or 1080i60 resolution (24-bit colour depth)

- FPD-Link III Outputs

- High Definition Multimedia (HDMI) v1.4b Input

- HDMI mode DisplayPort (DP++) input

- Supports up to 8 channels of HDMI audio extraction

- Automatic temperature and aging compensation with support for cables up to 15 metres long

- Spread spectrum input clock can be monitored to reduce EMI

- I2C (master/slave) with 1Mbps fast mode enhancement

- Compatible with DS90UB926Q-Q1 and DS90UB928Q-Q1 FPD-Link III Deserialiser

DS90UB929TRGCRQ1 Parameters

Input Type: HDMI

Output Type: FPD Link III, LVDS

Number of Inputs: 24

Number of Outputs: 1

Voltage - Supply: 1.71V ~ 1.89V

Operating Temperature: -40°C ~ 105°C (TA)

Grade: Automotive Grade

Qualification: AEC-Q100

Mounting Type: Surface Mount

Package/Housing: 64-VFQFN Undeposited Pad

DS90UB929TRGCRQ1 Applications

- Automotive infotainment systems:

- In-vehicle infotainment (IVI) hosts and human-machine interface (HMI) modules

- Rear seat entertainment systems

- Digital instrument clusters

- Surveillance cameras

- Consumer input HDMI port
