BQ296107DSGR is a high-accuracy, low-power overvoltage protector with a 2mA regulated output supply for Li-ion battery pack applications.

Specifications Of BQ296107DSGR

Function:Battery Protection

Battery Chemistry:Lithium Ion

Number of Cells:2 ~ 4

Fault Protection:Over Voltage

Operating Temperature:-40°C ~ 110°C (TA)

Features Of BQ296107DSGR

2-series, 3-series, and 4-series cell overvoltage protection (OVP)

Fixed delay timer to trigger FET drive output (3-s, 4-s, 5.5-s, or 6.5-s options)

Factory programmed OVP threshold (threshold range 3.85V to 4.6V)

Output options: active high

High-accuracy overvoltage protection: ±10mV

Regulated supply output with self-disable and/or external enable/disable control

Options: 3.3V, 2.5V, and 1.8V (BQ2961)

Options: 3.3V, 3.15V, 3.0V (BQ2962)

Low power consumption ICC ~ 4µA (VCELL(ALL) < VPROTECT)

Extra low power consumption with reg output disabled, ICC ~ 1.2µA

Low leakage current per cell input < 100nA

Small package footprint

8-Pin WSON (2mm × 2mm)

Applications Of BQ296107DSGR

Notebook PC

Ultrabooks

Medical

UPS battery backup
