The TPS65197BRUYR is an 8-channel level shifter with discharge capability, suitable for LCD display applications such as notebook computers, monitors, and televisions.

The TPS65197BRUYR converts timing controller (T-CON) logic level signals to the high-level signals required by Gate-in-Panel (GIP) displays.

The clock outputs CLKOUTx support standard level-shifting operation as well as 2-channel or 3-channel charge sharing, enabling improved picture quality and power consumption. During power-down, all outputs follow their input signals as closely as possible; when the discharge function is active, outputs are pulled high (VGH).

The TPS65197BRUYR performs a logic reset following the STV rising edge (which forces all six output clocks to VGL1) to ignore erroneous T-CON signals. The next CLKIN1 rising edge unlocks the logic and enables normal operation. The TPS65197BRUYR lacks a logic reset function, and all output signals continuously track their input signals.

TPS65197BRUYR Features

• 8-channel level shifter (STV, RESET, 6 × CLK)

• High output voltage level: 16.5V to 45V (VGH)

• Low output voltage level: down to –20V (VGL)

• Selectable charge sharing

– No charge sharing

– 2-channel charge sharing

– 3-channel charge sharing

• 2-channel panel discharge

• T-CON fault detection

– TPS65197B: No logic reset

• Latch-up shutdown detection (clock to VGH)

• Supports 100kHz clock operating frequency

• 28-pin 4mm x 4mm Quad Flat No-lead (QFN) package

TPS65197BRUYR Applications

• Gate-in-Panel (GIP) LCD

– Notebook computers

– Monitors

– Televisions
