Trade Name:RF Power Detector
Brand:ADI
Particular Year:22+
Package:WLCSP-6
Delivery Date:New and Original
Stock: 3000pcs
The ADL5506ACBZ is a complete, low-cost subsystem for RF signal measurements in the 30 MHz to 4.5 GHz frequency range, with a typical dynamic range of 45 dB, and is primarily intended for use in a wide range of wireless terminal equipment. It offers a wider dynamic range and higher accuracy than solutions with discrete diode detectors, with particularly good temperature stability over the -40°C to +85°C temperature range.
The higher sensitivity also allows measurements to be made at lower power levels, thus reducing the power consumption required for coupling to the detector. The device is essentially a voltage responsive device with a typical dynamic range of 45 dB.
For convenience, the signal is internally ac-coupled to a 52 Ω external shunt resistor using a 5 pF capacitor and a wideband 50 Ω matching resistor. This high-pass coupling allows for a lower operating frequency at a slew frequency of about 19 MHz. Therefore, the signal source can be DC grounded.
As the input signal level increases from 1.25 mV rms (-45 dBm) to 224 rms (0 dBm), the ADL5506 output rises from near 0.14 V to just over 1 V. The output is proportional to the logarithm of the input power level; in other words, the reading is presented directly in decibels, which is approximately 18 mV/dB at 900 MHz. time interval, a capacitor can be connected between the VLOG pin and the CFLT pin.
The ADL5506ACBZ is available in a 6-pin WLCSP package and consumes 3.8 mA at a supply voltage of 3.0 V. Typical disable current is less than 1 µA after shutdown.
Features (ADL5506ACBZ)
Full RF detector functionality
Typical dynamic range: 45 dB
Operating frequency range: 30 MHz to 4.5 GHz
Excellent temperature stability
Stable linear dB response
Power on/off response time: 65 ns/145 ns (rise/fall)
Applies -5 dBm input power
Operating temperature range: -40°C to +85°C
Low power consumption: 3.8 mA (3.0 V)
Supply voltage range: 2.5 V to 5.5 V
Disable current: less than 1 µA
AEC-Q100 certified for automotive applications
Applications (ADL5506ACBZ)
RSSI and TSSI for wireless end devices
RF transmitter or receiver power measurements
Automotive RF bi-directional amplifier
