ADL5513ACPZ: RF Power Detector - 1 MHz ~ 4 GHz , 80dB, Log Detector/Controller

Model: ADL5513ACPZ

Package: LFCSP-16

Type: RF Power Detector

Overview:

The ADL5513ACPZ is a demodulated logarithmic amplifier capable of accurately converting radio frequency (RF) input signals to the corresponding decibel scale output.The ADL5513 uses progressive compression in cascaded amplifier links, with each stage of the link equipped with a detector unit.

The ADL5513ACPZ can be used in measurement or controller mode. For signals above 4 GHz, the ADL5513 maintains accurate logarithmic coherence. Typical input dynamic range is 80 dB (impedance: 50 Ω) with an error of less than ±3 dB.

The ADL5513ACPZ has a response time of 10 ns and is capable of detecting RF pulses for pulse rates in excess of 50 MHz. The device provides unmatched logarithmic intercept stability over ambient temperature conditions.The ADL5513 operates from a supply voltage of 2.7 V to 5.5 V and consumes less than 30 mA of power, with lower currents when the device is disabled.

ADL5513ACPZ Product Features:

Wide bandwidth: 1 MHz to 4 GHz

Dynamic range: 80 dB (±3 dB)

Temperature stability: < ±0.5 dB

Low-noise measurement/controller output (VOUT)

Impulse response time: 10 ns

Small package size: 3 mm x 3 mm LFCSP

Supply: 2.7 to 5.5 V (30 mA)

Manufactured on a high-speed SiGe process ADL5513 consumes less than 30 mA. Manufactured on SiGe process

ADL5513ACPZ Applications:

RF transmitter amplifier setpoint control and level detection

Power detection in wireless link transmitters

RSSI measurement in base stations, WLAN, WiMAX, radar
