The TMS320F28377SPTPQ is a powerful 32-bit floating-point microcontroller unit (MCU) designed for advanced closed-loop control applications such as industrial motor drives, photovoltaic inverters and digital power supplies, electric vehicles and transportation, and sensing and signal processing.

Product Attributes

Core Processor: C28x

Core specification: 32-bit single core

Speed: 200MHz

Connectivity: CANbus, EBI/EMI, I²C, McBSP, SCI, SPI, uPP, UART/USART, USB

Peripherals: DMA, POR, PWM, WDT

Number of I/O: 97

Program memory capacity: 1MB (512K x 16)

Programme memory type: Flash

EEPROM Capacity: -

RAM Size: 82K x 16

Voltage - Supply (Vcc/Vdd): 1.14V ~ 3.47V

Data Converter: A/D 20x12b, 20x16b; D/A 3x12b

Oscillator Type: Internal

Operating Temperature: -40°C ~ 125°C (TA)

Mounting Type: Surface Mount

Package/Housing: 176-LQFP Exposed Pad

Supplier Device Package: 176-HLQFP (24x24)

Applications

- Medium/Short Range Radar

- Traction Inverter Motor Control

- HVAC Large Commercial Motor Control

- Automatic Sorting Equipment

- CNC Control

- AC Charging Stations

- DC Charging Stations

- Electric Vehicle Charging Station Power Modules

- Energy Storage Power Conversion Systems (PCS)

- Central inverters

- Solar Power Optimiser

- String Inverters

- Inverters and Motor Controls

- On-Board Chargers (OBC) and Wireless Chargers

- Linear Motor Segment Controllers

- Servo Drive Control Modules

- AC Input BLDC Motor Drivers

- DC Input BLDC Motor Drivers

- Industrial AC/DC Power Supplies

- Three-Phase UPS
