LTC1992HMS8 - Low Power, Unconstrained Fully Differential Amplifier, MSOP-8

Model: LTC1992HMS8

Package: MSOP-8

Type: Full Differential Amplifier

The LTC1992HMS8 is an unconstrained fully differential amplifier. The device has a separate internal common-mode feedback path for superb output phase balance and second-order harmonic reduction.The VOCM pin is responsible for setting the output common-mode level independent of the input common-mode level. This feature makes level shifting of the signal simple and easy.

LTC1992HMS8 - Product Features:

Adjustable Gain and Fixed Gain (1, 2, 5, and 10) Parts

±0.3% (maximum) gain error (over -40ºC to 85ºC temperature range)

3.5ppm/ºC Gain Temperature Coefficient

5ppm Long-term gain stability

Fully differential inputs and outputs

Stable with CLOADs as high as 10,000pF

Adjustable output common mode voltage

Rail-to-rail output swing

Low supply current: 1mA (max)

High output current: 10mA (min)

Technical specifications for 2.7V to ±5V supplies

DC offset < 2.5mV (max)

Available in 8-pin MSOP package

LTC1992HMS8 - Applications:

Differential Driver/Receiver

Differential amplification

Single-Ended to Differential Conversion

Level shifting

Tuned phase response for multi-channel systems
