The AD8139ARDZ is an ultra-low-noise, high-performance differential amplifier with rail-to-rail output. It features low noise, high SFDR, and wide bandwidth, making it an ideal choice for driving ADCs with up to 18-bit resolution. The AD8139ARDZ is easy to use, with an internal common-mode feedback architecture that allows the output common-mode voltage to be controlled by applying a voltage to a single pin. The internal feedback loop also provides excellent output balance and suppresses even-order harmonic distortion products. Using the AD8139ARDZ, it is easy to achieve fully differential and single-ended-to-differential gain configurations. A simple external feedback network consisting of four resistors determines the amplifier's closed-loop gain.

The AD8139ARDZ is manufactured using ADI's proprietary second-generation XFCB process, enabling low distortion characteristics with input voltage noise as low as 2.25 nV/√Hz.

The AD8139ARDZ is available in an 8-pin SOIC package with an exposed pad (EP) on the bottom, rated for operation over a temperature range of -40°C to +125°C.

AD8139ARDZ Product Attributes

Product Type: Differential Amplifier

Series: AD8139

Number of Channels: 1 Channel

GBP - Gain-Bandwidth Product: 410 MHz

SR - Slew Rate: 800 V/us

CMRR - Common-Mode Rejection Ratio: 84 dB

Output Current per Channel: 100 mA

Ib - Input Bias Current:    8 uA

Vos - Input Offset Voltage:    150 uV

Supply Voltage - Maximum:    12 V

Supply Voltage - Minimum:    5 V

Operating Supply Current:    24.5 mA

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +125°C

Mounting Style:    SMD/SMT

Package/Case:    SOIC-8

Gain V/V:    1 V/V

Input Voltage Range - Maximum:    3.8 V

Maximum Input Resistance:    3.5 MOhms

Operating supply voltage:    4.5 V to 6 V

PSRR - Power supply rejection ratio:    109 dB

Settling time:    45 ns

AD8139ARDZ product applications

ADC driver with up to 18-bit resolution

Single-ended to differential converter

Differential filter

Level converter

Differential PCB driver

Differential cable driver
