The AWB7227RM52P8 is a fully-matched multichip module (MCM) designed for picobase station, femtobase station, and customer premises equipment (CPE) applications. Its high linearity and efficiency meet the extreme demands of small cell infrastructure architectures.Designed for WCDMA, HSDPA and LTE air interfaces operating in the 2.11 GHz to 2.17 GHz bands, the AWB7227RM52P8 delivers up to +27 dBm WCDMA (64 DPCH) power with an ACPR of better than -50 dBc.It features a convenient +4.5 Volt, +4.5 Volt, +4.5 Volt, +4.5 Volt, +4.5 Volt, +4.5 Volt, +4.5 Volt, +4.5 Volt, +4.5 Volt, +4.5 Volt. Powered by a convenient +4.5 V supply with 30 dB of gain, the device is fabricated using advanced InGaP HBT MMIC technology for best-in-class reliability, temperature stability and ruggedness. The self-contained 7 mm x 7 mm x 1.3 mm surface mount package integrates an RF matching network optimised for output power, efficiency and linearity in 50 Ω systems.

AWB7227RM52P8 Parameters

Frequency: 2.11GHz ~ 2.17GHz

P1dB: 34.5dBm

Gain: 30.5dB

RF Type: HSDPA, LTE, WCDMA

Voltage - Supply: 4.5V

Current - Supply: 740mA

Test Frequency: 2.17GHz

AWB7227RM52P8 Features

InGaP HBT technology

-52 dBc ACPR @ ±5 MHz, +27 dBm

- 30.5 dB gain

High efficiency

Low transistor junction temperature

Matched to 50 Ω systems

Low-profile miniature surface-mount package; RoHS compliant

Multicarrier capability

AWB7227RM52P8 Applications

WCDMA, HSDPA and LTE air interfaces

Microcells, femtocells, home nodes

Customer Premises Equipment (CPE)

Data cards and terminals
