The LT6372HUDC-0.2 is a precision funnel instrumentation amplifier with level switching and output clamping using a proprietary, high-performance bipolar process that achieves outstanding accuracy and long-term stability. These features make the LT6372HUDC-0.2 suitable for industrial, automotive and instrumentation applications that require high precision, low noise and a wide power range ‌.

The LT6372HUDC-0.2 has the following features:

Single gain setting resistance: G = 0.2 to >200

Excellent DC accuracy

Input offset voltage: 60μV (Max)

Input offset voltage drift: 0.6μV/°C (Max)

Low total gain error: 0.012% (Max.) (G = 0.2)

Low gain drift: 35 ppm/°C Max (G > 0.2)

High DC CMRR: 80 dB (min) (G = 0.2)

Integrated output clamp

Integrated output level conversion

Input bias current: 800 pA (Max)

4 MHz - 3 dB bandwidth (G = 0.2)

Low noise:

0.1Hz to 10Hz Noise: 0.2μVP-P

1 kHz voltage noise: 7 nV/√Hz

Integrated input RFI filter

Wide power supply range 4.75V to 35V

Temperature range: -40 °C to 125°C

20-lead 3mm x 4mm QFN package
