The INA128UA is a low-power, general-purpose instrumentation amplifier with excellent accuracy. These amplifiers feature a versatile three-stage operational amplifier design and are compact in size, making them suitable for a wide range of applications. Even at high gain (200kHz, G = 100), the current-feedback input circuit provides a wide bandwidth.

The gain can be set within a range of 1 to 10,000 using a single external resistor. The INA128UA provides an industry-standard gain formula with a 50kΩ resistor.

INA128UA Features

• Low offset voltage: 50μV (maximum)

• Low drift: 0.5μV/°C (maximum)

• Low input bias current: 5 nA (maximum)

• Low noise: 8 nV/√Hz, 0.2 μVpp

• High CMR: 120 dB (minimum)

• Bandwidth: 1.3 MHz (G = 1)

• Input protection voltage up to ±40 V

• Wide supply voltage range: ±2.25 V to ±18 V

• Low static current: 700 μA

INA128UA Specifications

Product Type: Instrumentation Amplifier

Series: INA128

Number of Channels: 1 Channel

3dB Bandwidth: 200 kHz

SR - Slew Rate: 4 V/us

CMRR - Common-Mode Rejection Ratio: 120 dB

Ib - Input bias current:    5 nA

Vos - Input offset voltage:    250 uV

Supply voltage - Maximum:    36 V

Supply voltage - Minimum:    4.5 V

Operating supply current:    700 uA

Minimum operating temperature:    -40°C

Maximum operating temperature:    +125°C

Mounting style:    SMD/SMT

Package/Case: SOIC-8

Dual Supply Voltage: +/- 15 V

en - Input Voltage Noise Density: 8 nV/sqrt Hz

Gain Error: 0.012%

Gain V/V: 1 V/V to 10000 V/V

GBP - Gain Bandwidth Product: 1.3 MHz

Height: 1.58 mm

INL - Integral Non-Linearity: 0.012%

Length: 4.9 mm

Maximum Input Resistance: 100 GOhms

Operating Supply Voltage: 4.5 V to 36 V

INA128UA Applications

• Pressure Transmitters

• Temperature Transmitters

• Weighing Scales

• Electrocardiogram (ECG)

• Analogue input modules

• Data acquisition (DAQ)
