The STW48N60M2 device is an N-channel power MOSFET developed using MDmesh M2 technology. thanks to its strip layout and improved vertical structure, the device exhibits low on-resistance and optimized switching characteristics, making it suitable for the most demanding high-efficiency converters.

Product attributes

Manufacturer: STMicroelectronics

Product Type: MOSFETs

Technology: Si

Mounting Style: Through Hole

Package / Case: TO-247-3

Transistor Polarity: N-Channel

Number of Channels: 1 Channel

Vds - Drain-Source Breakdown Voltage: 600 V

Id-Continuous drain current: 42 A

Rds On - drain-source on-resistance: 70 mOhms

Vgs - Gate-source voltage: - 25 V, + 25 V

Vgs th - gate source threshold voltage: 2 V

Qg - gate charge: 70 nC

Minimum operating temperature: - 55 C

Maximum operating temperature: + 150 C

Pd - power dissipation: 300 W

Channel mode: Enhancement

Brand name: MDmesh

Series: STW48N60M2

Configuration: Single

Drop time: 119 ns

Product type: MOSFET

Rise time: 17 ns

Factory Pack Quantity: 600

Sub Category: MOSFETs

Typical Off Delay Time: 13 ns

Typical turn-on delay time: 18.5 ns

Unit weight: 6 g

Applications

- Switching applications
