The IKA15N60T is a high-performance insulated gate bipolar transistor (IGBT) belonging to the TRENCHSTOP™ family. It integrates a 600V, 15A IGBT and an inverted parallel fast recovery emitter control diode in a TO-220 Full-Pak package.

Parameters

Collector-emitter voltage: 600V

DC collector current: 15A (TC = 25°C), 10.6A (TC = 100°C)

Pulsed collector current: 45A

Diode forward current: 17.2A (TC = 25°C), 10.8A (TC = 100°C)

Diode pulse current: 45A

Gate-emitter voltage: ±20V

Short-circuit withstand time: 5µs (VGE = 15V, VCC ≤ 400V, Tj ≤ 150°C)

Maximum power consumption: 35.7W (TC = 25°C)

Operating junction temperature: -40°C to +175°C

Storage temperature: -55°C to +150°C

Isolation voltage: 2500Vrms

Features

Very low VCEsat: 1.5V (typical)

Low switching losses

Easy parallel switching: due to positive temperature coefficient of VCEsat

Very soft, fast recovery reverse parallel emitter control diode

Highly robust, temperature stable behaviour

Low electromagnetic interference (EMI)

Low gate charge

Very tight parameter distribution

Applications

Air conditioning

Inverters
