Service Telephone:86-755-83294757
Trade Name:Interface Serializers & Deserializers
Brand:Maxim
Particular Year:24+
Package:TQFN-56
Delivery Date:New and Original
Stock: 2000pcs
MAX96752GTN/V deserializers convert a single- or dual-link GMSL™ serial input to single or dual OLDI. They also send and receive side-channel and peripheral control data, enabling full-duplex, single-wire transmission of video and bidirectional data.
Features of MAX96752GTN/V
1 x 4, 2 x 4, or 1 x 8 OLDI Output Lane Configurations
3Gbps or 6Gbps Forward Link Rates for System and Power Flexibility
Full-Duplex Capability Over a Single Wire
Supports Up to 300MHz PCLK
Supports Video Replication and Dual-View Splitting for Driving Two Displays
Uses Low-Cost 50Ω Coax or 100Ω STP Cables
Forward and Reverse I2S or 7.1 TDM Audio
Optional Internal VDD Regulator
ASIL-Relevant Functional Safety Features
ASIL-B Compliant
16-Bit CRC Protection of Control Channel Data (I2C, UART, SPI, GPIO, Audio)
Retransmission of All Control Channel Data (I2C, UART, SPI, GPIO, Audio) Upon Error Detection
Optional 32-Bit Video Line Cyclic Redundancy Check (CRC)
Selectable Interrupts for Fault Detection
Video Watermark Detection
Performance Tools Ensure High Link Margin
Continuous Adaptive Equalization on GMSL links
Forward and Reverse Channel Pseudorandom Binary Sequence (PRBS) Generator and Checker for BER Testing of Serial I/O Links
Eye-Opening Monitor for Continuous Link Margin Diagnosis
Concurrent Control Channel for Device Configuration and Communicating with Remote Peripherals
I2C, UART, Pass-Through I2C/UART, SPI, and Tunneled or Register-Programmable GPIO
Settable Priority Levels
Eight Hardware Programmable Device Addresses
Up to 14 Programmable General Purpose Input/Output (GPIO)
Sleep Mode with Register State Retention
Compact 8mm x 8mm TQFN Package with Exposed Pad
Applications of MAX96752GTN/V
Cluster and Heads-Up Displays
Central Information Displays
Rear-Seat Infotainment Displays
