Trade Name:ISO7320FCQDRQ1
Data Manual:ISO7320FCQDRQ1.pdf
Brand:TI
Particular Year:23+
Package:SOP8
Delivery Date:New and Original
Stock: 8000pcs
The ISO7320FCQDRQ1 devices provide current isolation up to 1 minute and up to 3000 VRMS in accordance with UL 1577 and 4242 VPK isolation in accordance with VDE V 0884-10. These devices have two isolated channels with logic input and output buffers separated by a silicon dioxide (SiO2) insulating barrier.
The two channels of the ISO7320FCQDRQ1 are oriented in the same direction, while the two channels of the ISO7321-Q1 are oriented in opposite directions. In case of input power or signal loss, the default output level (device ordering part number with suffix) or level (device ordering part number without suffix) is used. For more information, see Device Functional Modes. When used with isolated power supplies, these devices help prevent noise currents on the data bus or other circuits from entering local ground or interfering with or damaging sensitive circuits. The ISO734x-Q1 series devices have integrated noise filters for harsh industrial environments. In such environments, short noise pulses may occur on the input pins of the device. The ISO732x-Q1 series devices have a transistor-transistor logic circuit (TTL) input threshold and operate over a voltage range of 3V to 5.5V.
Features
Compliant with automotive application requirements
With the following results in accordance with AEC-Q100.
Device temperature level 1: -40°C to +125°C ambient operating temperature range
Device Body Model (HBM) classification level 3A
Device Charge Device Model (CDM) classification level C6
Signal transmission rate: 25Mbps
Input with integrated noise filter
Default outputs and options
Low power consumption: ICC per channel typical (at 1Mbps)
ISO7320-Q1: 1.2mA (5V supply), 0.9mA (3.3V supply)
Low propagation delay: 33ns typical
(5V supply)
3.3V and 5V level conversion
65kV/μs Transient Immunity.
Typical (5V supply)
Excellent electromagnetic compatibility (EMC)
System level electrostatic discharge (ESD), transient discharge (EFT) and anti-surge protection
Low radiation
Isolation barrier life: > 25 years
Powered by 3.3V and 5V supplies
Narrow body small size integrated circuit (SOIC)-8 package
Applications
Photocoupler replacement products in the following applications.
Industrial FieldBus
- ProfiBus
- ModBus
- DeviceNet data bus
Servo control interfaces
Motor control
Power supply
Battery pack
Model
Brand
Package
Quantity
Describe
TI
SOIC-16
3000
Automotive-grade four-channel enhanced digital isolator with integrated 420kHz transformer driver
TI
SOIC-16
3000
Automotive-grade four-channel enhanced digital isolator with integrated 160kHz transformer driver
ADI
SSOP-20
5000
Compact, four-channel, 3.75 KV RMS digital isolator (3/1 channel directional)
ADI
SOIC-16
2000
Quad Isolator with integrated DC/DC converter (0/4 channel directional)
ADI
SSOP-24
2000
Robust 2.5 kV rms Quad Isolator with Integrated DC/DC Converter and 2 Inverting Channels
A: all online goods on the shelves can be ordered online, but considering the large liquidity of spot inventory, it is not possible to achieve 100% accuracy at present. In case of any abnormality, you can contact our company online and give the corresponding solution.
A: our self-supporting products are from cooperative domestic and foreign original factories or authorized agents, and the source can be traced to ensure the original and authentic products.
A: at present, our self-employed brands TI,ST,ADI,NXP,LATTICE,CYPRESS,INFINEON,XILINX and other first-line brands. Other channels are the original factory and agency channels. If necessary, we can communicate and confirm according to the specific brand and model.
A: You can inquire through the website, or by phone and email.
A: the delivery date is marked in most commodity information. You can estimate the delivery time of the commodity according to the delivery date. The specific arrival time depends on the warehouse where the commodity is located and the logistics mode you choose.
A: you can issue ordinary invoices for individual users or special VAT invoices for enterprise users.
Texas Instruments (TI), abbreviated as TI, is the worlds leading semiconductor company providing innovative digital signal processing (DSP) and analog device technologies for real-world signal processing. In addition to the semiconductor business, it …
DP83TC811SWRNDRQ1
The DP83TC811SWRNDRQ1 Low Power Automotive PHYTER 100BASE-T1 Ethernet Physical Layer Transceiver provides the physical layer functionality required for transmitting and receiving data over shielded single twisted pair cable. The device enables xMII fl…SN6505ADBVR
The SN6505ADBVR is a low noise, low EMI push-pull transformer driver designed for small isolated power supplies. The device drives a thin, mid-tap transformer from a 2.25V to 5V DC supply.BQ24203DGN
The BQ24203DGN is a single-cell Li-ion/polymer battery charge management IC in an 8-HVSSOP package designed for current limiting applications and is suitable for charge management of portable electronic devices.DRV110APWR
The DRV110APWR device is a PWM current controller for solenoid valves.UCC27523DR
The UCC27523DR devices are dual-channel, high-speed, low-side gate drivers that efficiently drive MOSFET and IGBT power switches.DAC70004IDMDR
The DAC70004IDMDR is an ultra-small, true 14-bit quAD output DAC with 1LSB INL/DNL, suitable for high-precision applications . The device operates within a temperature range of -40C to 125C, with a maximum analog output voltage of 5.5V and a minim…Contact Number:86-755-83294757
