The LT8640/LT8640-1 buck regulators are based on the Silent Switcher architecture and are designed to minimise EMI/EMC emissions and provide high efficiency at frequencies up to 3MHz. With an ultra-low quiescent current of 2.5µA (when the output is fully regulated), they are suitable for applications requiring extremely high efficiency at very low load currents. the LT8640/LT8640-1 can achieve high VIN to low VOUT conversion at high frequencies with a fast minimum tip switching on time of 30ns. the SYNC/MODE pin is responsible for Selecting between burst mode, spread spectrum mode, synchronisation to an external clock, and pulse hopping (LT8640) or forced continuous mode (LT8640-1).

Product specifications

Function Buck

Output Configuration Positive

Topology Step-Down

Output Type Adjustable

Number of Outputs 1

Voltage - Input (Min) 3.4V

Voltage - Input (Max) 42V

Voltage - Output (Min/Fixed) 0.97V

Voltage - Output (Max) 42V

Current - Output 6A

Frequency - Switching 200kHz ~ 3MHz

Synchronous Rectifier Yes

Operating Temperature -40°C ~ 150°C (TJ)

Mounting Type Surface Mount

Package/Case 24-TFQFN Exposed Pad

Supplier Device Package 24-LQFN (4x4)

Applications

Automotive and industrial power supplies

General purpose step-down

GSM power supplies
