NVMFS5C430NWFAFT1G is an automotive 40V, 185A, 1.7mΩ power MOSFET for compact and efficient designs, installed in a 5x6mm flat lead package with high thermal performance. Wettable flank options for enhanced optical inspection.

Product attribute

FET type: N channel

Technology: MOSFET (Metal oxide)

Drain-source voltage (Vdss) : 40 V

Current at 25°C - Continuous drain (Id) : 35A (Ta), 185A (Tc)

Drive voltage (Max Rds On, min Rds On) : 10V

On-resistance (Max.) at different ids and Vgs: 1.7 milliohm @ 50A, 10V

Vgs(th) (Max.) for different ids: 3.5V@250µA

Gate charge (Qg) at different Vgs (Max.) : 47 NC-@10 V

Vgs (Max.) : ±20V

Input capacitance (Ciss) for different Vds (Max.) : 3300 PF-@25 V

FET function: -

Power dissipation (Max) : 3.8W (Ta), 106W (Tc)

Operating temperature: -55°C ~ 175°C (TJ)

Class: Automobile class

Qualification: AEC-Q101

Mounting type: Surface mount, wets flanks

Supplier Device Package: 5-DFNW (4.9x5.9) (8-SOFL-WF)

Package/housing: 8-PowerTDFN, 5 leads

Basic product number: NVMFS5
