NCV7424DB0R2G is a four-channel physical layer device that uses the Local Interconnect Network (LIN) protocol. It supports the connection of four independent LIN physical buses and LIN protocol controllers. This device complies with the LIN 2.x protocol specification package and the SAE J2602 standard. The NCV7424DB0R2G LIN device belongs to the In-Vehicle Networking (IVN) transceiver series. This device is a single-chip solution with performance four times that of the NCV7321-1 transceiver.

Technical Specifications

Product Model: NCV7424DB0R2G

Protocol Support: LIN 2.x / SAE J2602

Operating Voltage: 5V to 27V (supports 12V/24V automotive systems)

Data Rate: 1kbps to 20kbps

Operating Temperature: -40°C to +125°C (AEC-Q100 Grade 1)

Package: 16-TSSOP (4.4mm × 5.1mm)

ESD Protection:    LIN pin ≥10kV (HBM)

Receiver Hysteresis:    100mV, enhanced noise immunity

Quiescent Current:    ≤30µA (standby mode)

NCV7424DB0R2G Features

TSSOP16 package. Pin layout compatible with single LIN NCV7321 transceiver (pins 4 to 7 and 10 to 13)

Compliant with LIN 2.x standard, backward compatible to version 1.3 and J2602

Data rate 1 kbps to 20 kbps

LIN bus provides unlimited short-circuit protection for power and ground lines

Bus pins are transient-protected in automotive environments

Thermal shutdown

System LIN pins withstand electrostatic discharge (ESD) exceeding 10 kV without external ESD protection

Load dump protection (45 V)

Integrated slope control enables excellent electromagnetic emission (EME) performance even without capacitors on the LIN pins

Excellent electromagnetic interference (EMI) performance

Remote wake-up via the LIN bus on all four channels

Compatible with 3.3 V and 5 V digital inputs
