Service Telephone:86-755-83294757
Trade Name:NCV7344D13R2G
Data Manual:NCV7344D13R2G.pdf
Brand:ON
Particular Year:23+
Package:8-SOIC
Delivery Date:New original
Stock: 2000pcs
NCV7344D13R2G CAN transceiver is the interface between a controller area network protocol controller and the physical bus. The transceiver provides differential transmit capability to the bus and differential receive capability to the CAN controller.
Features
Compatible with ISO 11898−2:2016
Specification for Loop Delay Symmetry up to 5 Mbps
VIO pin on NCV7344−3 Version Allowing Direct Interfacing with 3 V to 5 V Microcontrollers
Very Low Current Standby Mode with Wake−up via the Bus
Low Electromagnetic Emission (EME) and High Electromagnetic Immunity
Very Low EME without Common−mode (CM) Choke
No Disturbance of the Bus Lines with an Un−powered Node
Transmit Data (TxD) Dominant Timeout Function
Under All Supply Conditions the Chip Behaves Predictably
Very High ESD Robustness of Bus Pins, >8 kV System ESD Pulses
Thermal Protection
Bus Pins Short Circuit Proof to Supply Voltage and Ground
Bus Pins Protected Against Transients in an AutomotiveEnvironment
These are Pb−free Devices
Applications
Automotive
Industrial Networks
Model
Brand
Package
Quantity
Describe
TI
SOIC-14
10000
Automotive CAN FD transceiver with watchdog, bus diagnostics and partial networking via sele
