The RHRP8120-F102 is an extremely fast diode with soft recovery characteristics. It features the half recovery time of an ultra-fast diode and employs a silicon nitride passivated ion-implanted epitaxial planar structure. This device is suitable for use as a flyback/clamping diode, as well as in various switching power supplies and other power switching applications. Its low storage charge and ultra-fast soft recovery minimise ringing and electronic interference in various power switching circuits, reducing power consumption within the switching transistor.

RHRP8120-F102 Features

Ultra-fast recovery, Trr = 70 ns (at IF = 8 A)

Maximum forward voltage, VF = 3.2 V (at TC = 25°C)

1200 V reverse voltage and high reliability

Avalanche energy rating

RoHS compliant

RHRP8120-F102 Parameters

Product Type: Rectifier

Mounting Style: Through Hole

Package/Case: TO-220-2

Vr - Reverse Voltage:    1.2 kV

If - Forward Current:    8 A

Configuration:    Single

Vf - Forward Voltage:    3.2 V

Maximum Surge Current:    100 A

Ir - Reverse Current:    100 uA

Recovery Time:    70 ns

Minimum Operating Temperature:    -65°C

Maximum Operating Temperature:    +175°C

Series:    RHRP8120

Pd - Power Dissipation:    75 W

RHRP8120-F102 Applications

Switching Power Supplies

Power Switching Circuits

General Purpose
